Key Features
- Ultra-Compact Design: 8×8mm size enables discreet installation in tight spaces
- High Resolution Options: Available in 0.3MP configurations for enhanced image clarity
- Wide 115° Viewing Angle: Provides comprehensive coverage area
- Versatile Applications: Suitable for medical, security, industrial, and FPV applications
- Easy Installation: Designed for simple integration into existing systems
Technical Specifications
| Parameter | Value |
|---|---|
| Sensor | 1/4″ CMOS |
| Resolution | 0.3MP |
| Signal Type | CVBS |
| Frame Rate | 640×480@50fps |
| Operating Voltage | DC 3.3V |
| Dimensions | 8mm×8mm |
| Model Number | HCC-3P803 |
| Interface | 3pin |
| Lens | 1mm |
| Viewing Angle | 115 Degree |
| Resolution | 600TVL |
| Camera Used for | FPV drone |
- Machine vision and automated inspection
- Industrial equipment monitoring
- Medical imaging devices
- Robotics and automation systems
- Access control and security cameras
- Smart vending, kiosks, and terminals
- Laboratory instruments and optical systems
Customization Options
We are well aware of the unique visual requirements of different applications and provide comprehensive OEM/ODM customization services to help you create differentiated products.
1. Lens customization: specific focal length, field of view angle, distortion control.
2. Customized casing: Design a dedicated casing, bracket, or fixing method based on the structure of your device.
3. Cable and Interface: Customize cable length and interface type.
4. Pixel customization: Different resolution and frame rate models are available.
