Product functions and features
- High definition sensor performance: Supports high-resolution 2592x1944p image acquisition, providing exquisite image quality far exceeding 1080P, ensuring clear and sharp image details, and meeting the strict image quality requirements of various application scenarios.
- Stable USB interface and plug and play UVC protocol: The USB interface ensures compatibility with Windows, Linux, Android, and other mainstream platforms. This module adopts the UVC standard and does not require additional drivers, greatly reducing the development time and integration costs for B2B customers.
- Flexible lens selection: You can customize lens configurations such as wide-angle, narrow focus, fixed focus, or custom field of view to meet your application needs.
| Parameter | Value |
|---|---|
| Sensor | 1/4″CMOS |
| Pixel | 5MP |
| Compression format | MJPG/YUV2 |
| Frame rate | 2592X1944@30fps |
| Audio | Mic |
| Working voltage | DC 5V |
| Product size | 12mmX14.5mm |
| White balance | Automatic |
| Working temperature | <70°C |
| Power consumption | 0.25w |
| Model | HCU-P125(DZ) |
| Signal type | USB |
| Night vision function | Not supported |
|
Lens |
Effective length: 1.9mm Focal length: 2.2+3% Distortion: <-8.7% Mount: M6.5XP0.25 |
| FOV | 75° |
| Supported OS | Windows/Linux/Android |
This high-performance, small-sized camera module is an ideal choice for product development in the following fields:
Smart home devices: integrated into smart doorbells, smart cat eyes, home robots, baby monitors, smart refrigerators, etc., to achieve functions such as video calls, motion detection, and human recognition.
Security monitoring products: As the core imaging unit of micro network cameras, hidden cameras, and portable law enforcement recorders.
Industrial applications: Used for primary machine vision applications such as small size measurement, simple barcode recognition, and production line process monitoring.
Office and video conferencing: Embedded into video conferencing systems, smart whiteboards, and laptops, providing high-definition video input.
Intelligent transportation and in car electronics: can be used as a modular solution for driving recorders, in car monitoring cameras, and reversing cameras.
Explore more models in our USB Camera Module series to meet different application needs.
