Core Features
1. Ultra micro size: only 15 × 15mm, compact in size, suitable for internal embedding and concealed assembly of small devices.
2. 120 ° wide-angle field of view, single lens covers a larger shooting range, reduces monitoring blind spots, and does not require multiple lens combinations.
3. UVC Drive Free Plug and Play: USB 2.0 interface, compatible with Windows, Linux, Android, macOS, supports OTG direct connection to Android devices.
4. Stability 720P@30fps Output, low light CMOS sensor, can still output smooth and clear images in low light environments.
5. Support OEM/ODM customization, with adjustable lens angle, cable length, and interface type, suitable for batch project integration.
2. 120 ° wide-angle field of view, single lens covers a larger shooting range, reduces monitoring blind spots, and does not require multiple lens combinations.
3. UVC Drive Free Plug and Play: USB 2.0 interface, compatible with Windows, Linux, Android, macOS, supports OTG direct connection to Android devices.
4. Stability 720P@30fps Output, low light CMOS sensor, can still output smooth and clear images in low light environments.
5. Support OEM/ODM customization, with adjustable lens angle, cable length, and interface type, suitable for batch project integration.
Specifications
| Sensor | 1/4″ CMOS Sensor |
|---|---|
| Pixel | 1MP |
| Compression format | MJPG/YUV2 |
| Frame rate | 1280×720@30fps |
| Power Supply | DC 5V |
| Size | 15mmx15mm |
| Model Number | HCT-151J21-PG |
| Interface | Lightning |
| Lens | 2.1mm |
| FOV | 120 Degree |
Special Features | Support UVC |
| Support OS | IOS/Android/Windows |
Customization Options
We are well aware of the unique visual requirements of different applications and provide comprehensive OEM/ODM customization services to help you create differentiated products.
- Lens customization: specific focal length, field of view angle, distortion control.
- Customized casing: Design a dedicated casing, bracket, or fixing method based on the structure of your device.
- Cable and Interface: Customize cable length and interface type.
- Pixel customization: Different resolution and frame rate models are available.
Application Fields
Mobile external video capture, portable on-site recording, device debugging and testing, small embedded devices, IoT intelligent hardware, experimental collection, self-service auxiliary camera, industrial equipment visualization, teaching recording, special project development integration and other scenarios.
Browse more models in our USB camera series to meet different installation and integration requirements.
