Core functions of the product
1. 2mm ultra miniature probe size, extremely small volume, can penetrate into narrow gaps and holes for endoscopic detection.
2. With a 110 ° wide field of view, the camera has a wide shooting field of view, reducing blind spots and allowing for close range capture of large areas of footage.
3. 400 × 400P resolution, smooth output at 30fps, depth of field of 2mm to 5cm, suitable for close range endoscopic observation scenes.
4. Flexible cable design, flexible routing, TYPE-C direct connection, UVC drive free plug and play, easy deployment.
5. Support OEM customization, adapt to industrial testing and equipment development, compatible with multiple operating systems.
Specifications
| Description | OV6946 Endoscope Module |
| Pixel | 160,000 pixels |
Depth of field | 2mm-5cm |
| Resolution | 400 x 400P@30FPS |
| Power Supply | 3.3V |
light source | LED * 4 |
| Model Number | HCT-YL016NKJ |
Application | medical endoscope |
Sensor | CMOS Sensor |
Diagonal Field of View | 110 degree |
Customized Services
We understand the unique visual requirements of different applications and provide comprehensive OEM/ODM customization services to create differentiated products.
- Lens customization: Specific focal length, field of view angle, distortion control.
- Customized casing: Design dedicated casing, bracket, or fixing method based on your device structure.
- Cable and Interface: Customize cable length and interface type.
- Pixel customization: Different resolution and frame rate models available.
Camera application field
Industrial equipment gap detection, pipeline internal cavity inspection, equipment internal fault troubleshooting, instrument endoscopic testing, scientific research experiment observation, small equipment maintenance, medical endoscopic exploration and other scenarios.
Browse more models in our USB Camera series to meet different installation and integration requirements.
