| Specification | Detail |
|---|---|
| Sensor | 1/2.8″ |
| Pixel | 2MP |
| Signal | AHD |
| Frame rate | 1920×1080 25fps |
| Audio | Not supported |
| Working voltage | DC 3.3V |
| Product size | 30mm×30mm |
| White balance | Automatic |
| Working temperature | <70°C |
| Power consumption | 0.25 watts |
| Interface type | BNC |
| Lens specifications | Effective length: 3mm Focal length: 2.2 Distortion: <-1.0% Component: 4E+IR Angle: D=95° H=83° V=55° |
| Chip type | CMOS |
| Standard | PAL/NTSC (Default PAL) |
2 million pixel high-definition imaging: supports 1920 × 1080@25fps High definition video output with rich and clear picture details.
1/2.8-inch CMOS sensor: significantly improves sensitivity performance, still performs well in low light environments.
UTC coaxial control: supports calling up rich setting options through UTC function, remotely adjusting parameters through coaxial cable, without the need to configure control lines separately.
Compatible with traditional simulation systems and supports direct connection via BNC interface.
Metal heat dissipation shell: excellent heat dissipation performance, ensuring long-term stable operation.
Wide voltage design: Supports DC12V ± 30% wide voltage input, suitable for unstable power supply environments.
As a professional camera module supplier, we provide comprehensive OEM/ODM customization services:
- Lightweight customization service: Supports custom logo and product label design
- Customization based on drawings: The installation structure can be adjusted according to your drawings
- Sample customization: Providing sample development services to meet special application needs
- Customized on demand: For large quantities of customers, adjustable parameter specifications
